Wildy 16

$76,600 AUD

WILDY – 16: Rugged Comfort in a 16FT Off-Road Caravan (4 Berth)

Built for the wild. Designed for comfort. Ready for Australia.

• 7200mm L x 2320mm W x 3200mm H

*All weights are indicative and may vary depending on final configuration.

The WILDY – 16 is our premium 16-foot off-road caravan, engineered for families and adventurers who demand both durability and home-like comfort. With sleeping space for four, a full-size shower, roof air conditioning, and both indoor and outdoor kitchens, it offers true comfort off the grid.

Can be done in 2/4 Berth variants.
💬 Want a custom build? Contact our team to configure your own WILDY – 16 setup.

General Overview

Model: 16FT Off-Road Caravan
Internal Length: 16FT
Berths: Sleeps up to 4 persons
Construction: Heavy-duty galvanised steel chassis with aluminium composite panel body
Body Frame: Full steel internal frame construction

Weights & Ratings (Approx.)

Tare Weight: ~2200 kg
Tow Ball Weight: ~200 kg
ATM: 2800 kg
GTM: 2500 kg
Payload Capacity: ~600 kg

All weights are indicative and may vary depending on final configuration.

Dimensions (Incl. Air-con)

Overall Length: 7200 mm
Overall Width: 2320 mm
Overall Height: 3200 mm

Chassis & Running Gear

Heavy-duty Q355 galvanised steel drawbar, 150mm × 50mm RHS
50mm ball coupling
Jockey wheel
Independent coil spring trailing arm suspension
Dual shock absorbers per wheel
12” electromagnetic brakes + integrated handbrake
Drawbar-mounted emergency breakaway system
16” alloy wheels (16 × 7.5, 6/139.7 PCD)
265/75 R16 all-terrain tyres + 1 matching spare wheel
4 × heavy-duty adjustable drop-down stabiliser legs
1500kg high-lift scissor jack with integrated jacking points

Exterior Features

Large roll-out awning
Front-mounted LED light bar
2 × 8.5kg gas bottle holders
Water Storage: 2 × 80L fresh + 1 × 120L grey
12V marine-grade diaphragm water pump
Hot & cold external shower
Wall-mounted fold-down external servery table
Wireless rear-view camera (2.4GHz) + 7” portable monitor
Marine-grade composite body with steel frame construction
Aluminium checker plate side protection (750mm height)

Interior & Comfort

Sleeping: 1 × Queen bed + 1 × double bunk bed
Lounge: Convertible L-shape lounge (small single equivalent)
Modern oak-look laminate benchtops
Black matte finish sink and tapware
Shower ensuite
Double-glazed tinted acrylic windows
Integrated flyscreen + block-out blind
Bathroom: 12V roof vent skylight + fan + LED lighting

Major Appliances

Dometic roof-mounted reverse-cycle air conditioner
FOGGTI gas hot water system
50L SANJ 12V compressor refrigerator
Built-in microwave oven – 20L / 800W

Electrical System

Solar: 3 × 165W panels (Total 495W)
MPPT solar charge controller
Battery monitoring system
3000W pure sine wave inverter
Integrated inverter & charger
Internal 12V LED lighting throughout
External 12V LED lighting (awning white + yellow bug light)
Position markers, indicators & tail lights
7-pin flat trailer plug
Stereo head unit with internal & external speakers
Pre-wired TV point (TV not included)
12V RV range hood

Gas & Cooking

Australian standard gas system with copper piping
Internal two-burner gas cooktop
Outdoor kitchen: two-burner stove + sink

Power Outlets

Internal: 12V sockets, Dual USB (1A & 2A), 240V GPOs, TV outlet, reading lights with USB
External: 12V socket, Dual USB (1A & 2A), 240V external GPO

×
